Star Micronics 40mm Diamond-Coverage Linerless Sticky Label Paper, 170 ft, 24 Rolls, 37990090
Star Micronics 40mm Diamond-Coverage Linerless Sticky Label Paper, 170 ft, 24 Rolls, 37990090
Compatible with:
37990090
Couldn't load pickup availability
Free Shipping Over $500
Fully Secure Checkout
Shop with confidence
Customer Support
Need help choosing the right configuration?
Talk with a Spartan POS hardware specialist about compatibility, accessories, quantities, or deployment requirements.
Product Description
Star Blue Eco 40 mm Diamond-Coverage Linerless Label Paper
Star Micronics 37990090 (TRK40-D83-C25 KD SBE 24PK) is a 24-roll case of removable direct thermal linerless sticky paper for the Star TSP143IV SK. Each white roll is 40 mm (1.57") wide, approximately 170 feet long, has an 83 mm outside diameter and uses a 25 mm core.
Quick Answer
What is Star part 37990090? It is 40 mm Star Blue Eco linerless label paper with diamond adhesive coverage, packed 24 rolls per case. It is compatible with all four TSP143IV SK printer versions. Diamond-pattern adhesive provides lighter contact for repositionable labels that need clean removal.
Key Features
- 40 mm (1.57") continuous linerless thermal media
- Diamond-coverage removable adhesive
- Approximately 170 feet per roll
- 83 mm maximum roll diameter with 25 mm core
- 24 rolls per case
- No silicone liner to peel away or discard
- No ink, toner or thermal-transfer ribbon required
- Repositionable for cups, bags, containers, shelves and order workflows
- Star Blue Eco, Prop 65-compliant and formulated without BPA/BPS
Compatible Printers
- 39473310 — StarPRNT, USB-C and Ethernet
- 39473910 — StarPRNT X4, USB-C, Ethernet, Wi-Fi and Bluetooth
- 37952430 — ESC/POS, USB-C and Ethernet
- 37952450 — ESC/POS X4, USB-C, Ethernet, Wi-Fi and Bluetooth
Compatibility warning: This is an 83 mm-diameter roll for the TSP143IV SK. It is not the larger 101 mm-diameter media sold for the Star mC-Label3.
Diamond Coverage vs Full Coverage
Diamond-pattern adhesive provides lighter contact for repositionable labels that need clean removal.
Need the other adhesive pattern in the same width? See 37951970, 40 mm full coverage.
Other Diamond-Coverage Sizes
All Compatible TSP143IV SK Paper
- 37990090 — 40 mm diamond-coverage adhesive, 24 rolls/case
- 37951970 — 40 mm full-coverage adhesive, 24 rolls/case
- 37990080 — 58 mm diamond-coverage adhesive, 24 rolls/case
- 37951980 — 58 mm full-coverage adhesive, 24 rolls/case
- 37990070 — 80 mm diamond-coverage adhesive, 24 rolls/case
- 37951990 — 80 mm full-coverage adhesive, 24 rolls/case
Specifications
| Manufacturer part | 37990090 |
|---|---|
| Model | TRK40-D83-C25 KD SBE 24PK |
| Print technology | Direct thermal |
| Width | 40 mm (1.57") |
| Roll length | Approximately 170 ft |
| Outside diameter | 83 mm |
| Core | 25 mm |
| Adhesive | Diamond coverage, removable and repositionable |
| Case quantity | 24 rolls |
Frequently Asked Questions
Is 37990090 sold by the roll or by the case?
This listing is for one case containing 24 rolls.
Does this paper need a ribbon?
No. It is direct thermal media and does not require ink, toner or a thermal-transfer ribbon.
Is this ordinary receipt paper?
No. It is continuous linerless sticky thermal media with removable adhesive. It is designed to create variable-length sticky labels and adhesive receipts.
What is the difference between diamond and full adhesive?
Diamond coverage uses a patterned adhesive area for lighter contact. Full coverage applies adhesive across more of the media surface. Both are removable and repositionable when used on suitable clean surfaces.
Will 37990090 fit the mC-Label3?
This 83 mm-diameter roll is specified for the TSP143IV SK. The mC-Label3 uses different 101 mm-diameter supply SKUs, so do not substitute them.
Manufacturer Resources
View Star Micronics specifications for 40 mm TSP143IV SK linerless paper.
Bottom Line
Order 37990090 when you need a 24-roll case of 40 mm Star Blue Eco linerless sticky media with diamond adhesive coverage for a TSP143IV SK printer.
